846633-B21 - Серверные сетевые контроллеры HPE
Dimensions & Weight
- Depth
- 11.9 in
- Height
- 0.9 in
- Weight
- 3.81 lbs
- Width
- 8.6 in
Environmental Parameters
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Max Operating Temperature
- 95 °F
- Max Storage Temperature
- 140 °F
- Min Operating Temperature
- 50 °F
- Min Storage Temperature
- -22 °F
Expansion / Connectivity
- Interfaces
- 4 x 10Gbit/40Gbit LAN QSFP ¦ 2 x 1/10Gbit LAN SFP+ ¦ 1 x console RJ-45
General
- Authentication Method
- RADIUS, TACACS
- Capacity
- VLAN IDs: 4094 ¦ IGMP groups: 1024
- Compliant Standards
- IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1v, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qbg, IEEE 802.1r
- Device Type
- Switch - L3 - managed
- Enclosure Type
- Plug-in module
- Encryption Algorithm
- IKE
- Features
- BOOTP support, port mirroring, IPv6 support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Per-VLAN Spanning Tree (PVST), Multiple Spanning Tree Protocol (MSTP) support, Data Center Bridging Exchange (DCBX) support, Quality of Service (QoS), Committed Access Rate (CAR), Jumbo Frames support, Equal-Cost Multipath (ECMP), Endpoint Admission Defense (EAD), LLDP support, Management Information Base (MIB), dynamic ARP protection, Multiple VLAN Registration Protocol (MVRP), NTP time synchronization, Strict Priority (SP), sFlow v5, Intelligent Resilient Framework Technology (IRF), Type of Service (ToS), Virtual Private LAN Service (VPLS), system log, IP source guard, Shortest Path Bridging (SPB), Internet Control Message Protocol (ICMP), NPV Gateway mode, Transparent Interconnection of Lots of Links (TRILL), Virtual Extensible LAN (VXLAN), Software Defined Networking (SDN), policy based routing, User Datagram Protocol (UDP), PVLAN edge, Protocol Independent Multicast (PIM), Weighted Round Robin (WRR)
- Flash Memory
- 512 MB
- Jumbo Frame Support
- 10KB
- MAC Address Table Size
- 288K entries
- Performance
- Uplink bandwidth: 180 Gbps ¦ Bandwidth: 240 Gbps ¦ Throughput: 1.2 Tbps ¦ Latency: 1.3 µs
- Ports
- 4 x QSFP + 2 x SFP+
- RAM
- 2 GB
- Remote Management Protocol
- SNMP 1, SNMP 2, SNMP, SNMP 3, SNMP 2c, HTTPS, SSH, SSH-2
- Routing Protocol
- OSPF, RIP, RIP-1, RIP-2, BGP, IGMP, VRRP, IGMPv3, OSPFv3, MSDP, ECMP, MPLS, CIDR, BGP+, URPF
- Status Indicators
- Power, link OK, link/activity
- Subtype
- 40 Gigabit Ethernet
Manufacturer Warranty
- Service & Support
- Limited warranty - parts and labor - 3 years - on-site
Miscellaneous
- Compliant Standards
- FCC Class A certified, ICES-003 Class A, AS/NZS 3548 Class A, VCCI Class A, IPsec/IKE
Power
- Power Consumption Operational
- 112 Watt
